Design, Fabrication and Evaluation of a Mini-Biogas Plant with Automatic Pressure Relief Control for Power Generation
DOI:
https://doi.org/10.65150/EP-gjetr/V2E7/2026-08Keywords:
Biogas, Anaerobic Digestion, Mini Biogas Plant, Pressure Relief System, Power Generation.Abstract
The growing demand for decentralised, sustainable power in Nigeria, combined with the poor management of organic waste in rural and peri-urban areas, motivates the development of small-scale, waste-to-energy technologies. This paper reports the design, fabrication and performance evaluation of a mini-biogas plant that converts cow dung and kitchen waste into electricity through anaerobic digestion, gas conditioning and a modified petrol generator, while a fully passive, electronics-free automatic pressure relief system based on an adjustable water seal protects the digester from over-pressurisation. The 1000 L high-density polyethylene (HDPE) digester was filled with 70% cow dung and 30% kitchen waste in the ratio of 1:1 of dung to water and kept under observation for 5 weeks of retention time.The pH of digester was maintained in the desired range of 6.8 to 7.5 from Week 2 onwards whereas the average digestion temperature ranged from 28.1 °C to 30.8 °C. Average biogas production was 0.92 m³/day (design target 0.5-1.5 m³/day), with a peak of 1.18 m³/day. Gas conditioning raised methane content from 58.4% in the raw biogas to 67.2% after CO₂ scrubbing, within the 60-70% target band. The water-seal pressure relief system activated within 3-4% of its calculated set point at all three tested submerged depths (8, 10 and 12 cm) and re-sealed within 4-6 seconds, confirming that safe, automatic pressure regulation can be achieved without sensors, controllers or external power. These results demonstrate that a low-cost, locally fabricated mini-biogas system with a passive safety mechanism is a technically viable route to decentralised electricity generation and organic-waste management in resource-limited settings.
References
1) Abah, M. A., et al. (2025). Life cycle assessment of bioenergy systems versus fossil fuel alternatives: Insights for sustainable energy transitions in Nigeria. Trends in Ecological and Indoor Environmental Engineering, 3(2), 46–59.
2) Abdurrakhman, A., Sutiarso, L., Ainuri, M., Ushada, M., & Islam, M. P. (2024). Design of a pressure control system in biogas reactor based on PID controller with Ziegler-Nichols and auto tuning PSO. Jurnal Otomasi Kontrol dan Instrumentasi, 16(2), 104–116.
3) Aini, N. U., Pujiyati, S., Hestirianoto, T., Rahmat, A., Santosa, J., & N., N. K. (2025). Design of gas pressure and pH pressure monitoring and control system using ESP32 on IoT-based biogas digester. Journal of Applied Sciences, 2(5).
4) Angelidaki, I., Batstone, D. J., & Holm-Nielsen, J. B. (2020). Anaerobic digestion: Process, modeling and applications. Biotechnology Advances, 38, Article 107408.
5) Bamiyo, A., Adebayo, O., & Abdullahi, M. (2021). Performance evaluation of a small-scale biogas digester using cow dung. Energy Reports, 7, 123–130.
6) Bamiyo Dirisu, G., Ekpa, M. M., & Gabriel Dirisu, C. (2023). Biogas production from co-anaerobic digestion of cow dung and fruit peel in a small-scale galvanized steel anaerobic digester. American Journal of Energy Research, 11(2), 56–62.
7) Batstone, D. J., Keller, J., Pikaar, I., & Jungles, S. J. (2021). The IWA anaerobic digestion model No. 1 (ADM1): A review and updates. Water Science and Technology, 84(5), 1059–1072.
8) Eze, C. N., Okafor, E., & Nwoye, S. (2021). Experimental investigation of biogas production from cow dung using a batch digester. Renewable Energy, 172, 1–9.
9) Jameel, M. K., et al. (2024). Biogas: Production, properties, applications, economic and challenges: A review. Results in Chemistry, 7.
10) Khalil, M., Raza, A., & Abbas, M. (2022). Portable biogas digester: A review. Engineering Proceedings, 32(1), Article 12.
11) Kumar, S., et al. (2022). Advances in sensor-based monitoring of biogas plants. Renewable Energy, 189, 123–135.
12) Lindkvist, E., et al. (2021). A review of household biogas systems and their application in developing countries. Renewable and Sustainable Energy Reviews, 140, Article 110682.
13) Nelson, J. (2021). Renewed for the future: Renewable and non-renewable energy sources and their costs.
14) Obileke, K. C., Makaka, G., Tangwe, S., & Mukumba, P. (2025). Improvement of biogas yields in an anaerobic digestion process via optimization technique. Environment, Development and Sustainability, 27(7), 15025–15051.
15) Ofoefule, S., Uzodinma, C., & Nwankwo, N. (2022). Biogas production from co-digestion of cow dung and organic waste. Renewable Energy, 185, 456–464.
16) Okoro, C., Musa, I., & Bello, F. (2022). Biogas production from household organic waste: Performance evaluation. Journal of Energy in Southern Africa, 33(2), 45–53.
17) Okoro, P. A., Chong, K., & Röder, M. (2024). Enabling modern bioenergy deployment in Nigeria to support industry and local communities. Biomass and Bioenergy, 190.
18) Oladosu, O. A., et al. (2024). Fabrication and characterization of Co and Li doped TiO2 photoanodes for high-efficiency dye-sensitized solar cells. Nigerian Journal of Physics, 33(4), 21–31.
19) Oluwaseun, A. O., & Titiladunayo, I. (2025). Sustainable biogas: An attempt at blending tradition and innovation for green energy through co-digestion of cow dung and elephant grass. European Journal of Sustainable Development Research, 9(3).
20) Ryckebosch, J., Drouillon, M., & Vervaeren, H. (2022). Techniques for transformation of biogas to biomethane. Biomass and Bioenergy, 35(5), 1633–1645.
21) Saleem, M. (2022). Possibility of utilizing agriculture biomass as a renewable and sustainable future energy source. Heliyon, 8(2).
22) Scarlat, M., Dallemand, J.-F., & Fahl, F. (2020). Biogas: Developments and perspectives in Europe. Renewable and Sustainable Energy Reviews, 129, Article 109602.
23) Shonhiwa, C., Mukumba, P., & Makaka, G. (2025). Techno-economic analysis of a mini biogas electricity plant (MBEP) for a typical farm in the Zimbabwean off-grid areas. Biomass Conversion and Biorefinery, 15(3), 4579–4595.
24) Singh, R., Kumar, A., & Verma, P. (2023). Performance evaluation of biogas production from co-digestion of agricultural and animal waste. Energy Reports, 9, 210–218.
25) Uyar, T. S., & Javani, N. (Eds.). (2022). Renewable energy based solutions. Springer International Publishing.
26) Yadav, G., et al. (2022). Performance analysis of biogas fueled internal combustion engine. Energy Reports, 8, 1234–1242.
27) Zhang, Y., Wang, L., & Li, Q. (2020). Anaerobic digestion of food waste for biogas production: Experimental study. Bioresource Technology, 300, Article 122666.
